Guide TS632L 35mm 640x512 Laser Range Finder Thermal Scope

The TS2 Series thermal imaging scope is a powerful, lightweight optical device. It features a 12µm high-sensitivity thermal sensor and a full-HD 1920×1080 AMOLED display for detailed, rich images. With a magnesium alloy housing, the TS2 Series remains lightweight even with the built-in laser rangefinder. The IP68 waterproof and dustproof design and high shock resistance ensure reliable performance in harsh conditions.

Features for Guide TS632L 35mm 640x512 Laser Range Finder Thermal Scope:

• Sensitive IR detector Crisp image resolution: The TS Gen2 Series is equipped with a 12µm infrared detector, offering multiple infrared resolution configurations, with NETD as low as 20mK. The 35mm lens provides a detection range of up to 1800 meters.
• Continuous zoom Quick target locking: The electronic zoom ring design brings easy and convenient rotation, offering a comfortable handling experience that helps you quickly and effortlessly lock onto targets.
• Accurate laser ranging Up to 1000m: The TS Gen2 Series integrates a highly accurate laser rangefinder with a maximum detection range of 1000 meters, paired with TargetIR Ballistics APP to enable long-range precision shooting.
• Dual-side focus knob Ergonomic design: The button and interaction design emphasizes user experience in practice, simplifying the steps for easy use. The dual-side focusing knob and rotary menu knob provide convenience for nighttime outdoor operation.
• Smart recording Breathtaking shots: During shooting, the TS Gen2 Series automatically records a 15-second video before and after the shot and captures five photos after to highlight key moments.
• 1000G shock resistance: Built with high-quality standards, the TS Gen2 Series features impeccable shock resistance of up to 1000G, protecting against recoil forces, shocks and vibrations.
• IP68-rated waterproof: The highly protective shell achieves a submission waterproof rating, ensuring worry-free outdoor adventures.

Specifications for Guide TS632L 35mm 640x512 Laser Range Finder Thermal Scope:

Sensor:

• Type: Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution: 640×512@12µm
• NETD: 20mK
• Frame Rate: 50Hz

Lens:

• Objective Lens: 35mm, F1.0
• Field of View: 12.5°×10°
• FOV m@100m: 22×17
• Magnification: 1.7x~13.6x
• Detection Range: 1800m/1950yd
• Focus: Manual

Display:

• Display Type: 0.39'' AMOLED 1920×1080
• Color Palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eye Relief: 48mm; Diopter -5 to +5; Zoom: 14x

Hardware:

• Laser Rangefinder: 1000m/1090yd
• Wifi: 2.4G, 5G
• Interface: USB Type-C
• Others: Microphone, Bluetooth

System:

• Recording Function: Photo/Video (Audio recording included)
• Memory Capacity: 64GB

Power:

• Battery Type: Single, replaceable 18650 battery
• Operating Time: 5.5 hours

Environmental:

• Operating Temp: -20°C to 50°C / -4°F to +122°F
• Shock: 1000G (as per IEC60068-2-27)
• Encapsulation: IP68

Physical:

• Weight (g/oz): 622/21.94
• Size (mm/in): 223×75×86/8.78×2.95×3.4
• Standard: Device, Lens cover, Eye mask, Quick-release scope mount, 18650 battery×2, Battery charger, 5V2A adapter (US, Britain, Australia and Europe), USB Type-C cable, Quick use guide, Safety Information Manual, Warranty card
• Optional: Bluetooth remote control, 18650 battery
