Guide TD361 LRF Thermal Monocular Handheld

Second hand item pictured: The Thermal Handheld pictured may not be the exact item available for sale as we may have more than one item in stock under this product code. This thermal monocular is located at our Cranford, Christchurch store. If you would like pictures of the exact item available, please contact the stocking store.

The TD Gen2 LRF Series thermal monoculars are the industry's first entry-level full-featured handheld thermal imaging monoculars. While inheriting the characteristics of the previous generation, such as being lightweight, portable, easy to operate, and durable, it integrates a high-precision laser rangefinder module to accurately detect targets within 600 meters. This thermal handheld adopts an AMOLED display, providing clear imaging and a comfortable viewing experience, making it the ideal equipment for outdoor night vision.

Thermal Monocular Features

• 640x480 IR Resolution
• 35mm/F1.0 Focal Length
• Manual Focusing
• 8 Hours Strong Battery Life
• Integrated Rangefinder (range up to 600m)
• High-brightness AMOLED Display
• Enhanced Image Processing Algorithms
• Real-time Sharing with WIFI

Thermal Monocular Specifications

Infrared detector:

• Detector type: Uncooled VOx Infrared
• Detector resolution and pitch: 640 × 480, 12 µm
• Spectral range: 8 to 14 µm
• NETD: =35 mk
• Frame rate: 50 Hz

Lens

• Focal length: 35 mm; F1.0
• Focus: Manual
• Field of View: 12.5° × 9.4°
• Optical zoom: 1.7x
• Digital zoom: 1x, 2x, 4x

Display

• Display type: 0.23" AMOLED
• Resolution: 640 x 400
• Eyepiece: Exit pupil distance=12 mm; Diopter: -4 to +2; Zoom: 18x
• Video output: Analog video

Power

• Battery type: Single Replaceable 18650 battery
• Battery life: = 8 hours

Interface

• USB: Type C
• Mechanical interface: UNC ¼"-20 (Tripod mounting), Mechanical expansion interface

Range Performance

• Detection range: 1400 m

Laser rangefinder

• Max. measuring range: 600m
• Others: PIP, Hot spot tracking

Functions

• Scene modes: Enhanced, Highlight and Natural
• Color palettes: Black Hot, White Hot, Red Hot, Iron Hot, Blue Hot
• PIP: Available
• Hot spot tracking: Available
• Rough ranging: Available with APP
• WIFI: 2.4 G
• Supported Application: TargetIR
• Firmware OTA: Upgrade device firmware via app connection

Environmental

• Storage temperature range: -30°C to 60°C
• Humidity: 10 % to 95 % non-condensing
• Shock: 30 G at 11 ms half-sine pulse
• Drop: 1 m
• Encapsulation: IP66
• Certification: IP66, FCC, CE, RoHS, EAC, WEEE, un38.3, IEC 60825-1 Class 2

Physical:

• Weight: = 399 g
• Dimensions: 150 × 77 × 74 mm

Included in box:

• Guide TD631 LRF
• Lens cover and lanyard
• Battery charger
• Single 18650 battery
• USB Type-C cable
• Wrist strap
• Carry bag
• Quick use guide
• Warranty card
